The Monarch still have that 25deg skid foward bias. We wanted to get in the short frame game so here we are . Plenty of breakover we put holes for a bearing carrier and plenty of shock adjustments. Also pulled the back of the rail up to keep that drive shaft and links tucked up as much as we can. If you run a link riser you will have to bend uppers.
You will receive
2x Carbon rails
1x single unicorn mount
1x high rise rear unicorn mount
2x 70mm stand off
1x skid of choice
1x set of mini sliders for 1/16 body
1-regular sliders
1xbearing carrier
You will have to buy links or make your own.
Options so far are dlux portal, dlux od3, blank transmission.
This is set up to run 4 link soa and outrunner motor Some motors will be a tight fit requiring to flip the top link bolt and put nut on out side of frame.!!
Link sizes are
62.5 upper front
67.5 lower front
180mm rear uppers
187mm rear lowers
That is end to end not eye to eye. Dlux fab has pre cuts in stock. You can get them https://dluxfab.com/Links-Rod-Ends-c6232187
This is based off of capra axles at wheelbase 13.5
