The Orb is Designed with a flat skid to meet c1 rules .We all so pushed the skid forward for better weight distribution.
You will receive
2- Carbon fiber chassis rails
R/L sliders
1x skid plate
2x 70mm standoffs
1x panhard cms mount
You will have to buy links or make your own.This is set up to run pan hard bar with cms you can also run it 4link if your local group does not go by sorcca rules. Designed around out runner style motors. Some motors will be a tight fit requiring to flip the top link bolt and put nut on out side of frame.!! I am running ar45p axles. 12.3 wheel base ..
Links are 80mm pan hard bar
Front up 62.5
Front low 67.5
Rear up 142.5
Rear lower 155
Bend Rear lower links towards axle for high clearance I use Dlux fab for TI links. They will have what you need
These are end of link to end of link
****NOT eye to eye****
Mike C
store owner
Just making some bad ass rigs for every one to enjoy.
